High Loading Capacity Coal Mine Dump Trucks 70 Tons With SGS ISO

High Loading Capacity Coal Mine Dump Trucks 70 Tons With SGS ISO

  • High Loading Capacity Coal Mine Dump Trucks 70 Tons With SGS ISO
  • High Loading Capacity Coal Mine Dump Trucks 70 Tons With SGS ISO
  • High Loading Capacity Coal Mine Dump Trucks 70 Tons With SGS ISO
  • High Loading Capacity Coal Mine Dump Trucks 70 Tons With SGS ISO
High Loading Capacity Coal Mine Dump Trucks 70 Tons With SGS ISO
Thông tin chi tiết sản phẩm:
Place of Origin: China
Hàng hiệu: SINOTRUK HOWO 70 Mining
Chứng nhận: ISO/3C/BV/IFA/SGS
Model Number: ZZ5707S3840AJ
Thanh toán:
Minimum Order Quantity: 1 Unit
Giá bán: USD78000-USD81000/UNIT)negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2,000units per month
Tiếp xúc
Chi tiết sản phẩm
Cargo body: 5800*3100*1600mm Loading capacity: 70tons
Product Name: Tipper Dump Truck Model: ZZ5707S3840AJ
Drive type: LHD 6X4 Emission Standard: Euro 2
Engine: WD615.47, 371HP
Điểm nổi bật:

sinotruk howo dump truck

,

commercial dump truck

High Loading Capacity SINOTRUK HOWO Coal Mine Dump Trucks 70 Tons With SGS ZZ5707S3840AJ





Description:



HOWO Mining Dump Truck with unilateral high strength skeleton cab, modelling concise, hale and hearty, broaden their horizons; good sealing can ensure your vehicle is always in the safe and comfortable driving environment; there are each of the two lighting lamps at the top of cabin's front and back for night work.



Equipped with a 500 liter D type fuel tank (optional 400 liters fuel tank), the workload of vehicle to meet your requirements.



SINOTRUK independent research and development of new front axle assembly, the application of the whole casting strander beam, 500x210 strengthen type brake for truck parts assembly technology.

Rear axle adopts AC26 mine driving axle, the main reducer structure design more reasonable, strengthen type casting bridge shell and drum brake the vehicle carrying capacity and braking ability in the leading domestic level.





Specification:



High Loading Capacity SINOTRUK HOWO Coal Mine Dump Trucks 70 Tons With SGS

Model  ZZ5707S3840AJ
Drive Type 6×4
Engine

WD615.47 , 371HP( Euro II)

6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

Displacement : 9.726L

Cabin HW7D   unilateral high strength skeleton cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW19710(10 forwards & 2 reverses)
Front Axle 1×HF12 ( 12 Tons)
Driving Axle AC26, 26Tons
Steering ZF8118 hydraulic steering with power assistance.
Clutch Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance
Rim/ Tire 14.00-25,14.00R25,Radial tire
Wheel base 3800+1500(mm)
Overall dimension 8700×3300×3670(mm)
Cargo body

5800×3100×1600(mm),Bottom:16mm, Side:12mm

The curb weight 23000(Kg)
Gross weight 70000 kg
Max. speed 50km/h
Color White, red, green, golden and so on.




Applications:



HOWO 70 Mining Dump Truck is heavy concentrated engineering design personnel and development, first and foremost applies to all kinds of open pit coal mine, steel mills, hydropower construction, dock, poor road conditions, homework is in bad situations in areas within a short distance transport business development of this car, in terms of the particular user groups, with high economic benefit and social benefit.





Competitive Advantage:


1) using the high strength steel, make it has a long service life
2) The HYVA Europe advanced hydraulic control system helps to avoid wrong operation, it has higher

safety and  running efficiency.
3) excellant apperance of cabin, safety, reliable
4) low fuel consumption
5) strong enough engine
6) with all kinds of truck model, which can fulfil your requirements
7) the key parts adopt the world's top technology products
8) based on strong technical support and top level technology make the trucks with high

quality and more reliable
9) competive price, cost-effective
10) quick and efficient spare parts supply bring you more convenient
11) fast delivery time, we can arange production according to your needs exactly and

quickly

12) professional import and export dealing precedure, make customs clearance more high efficiency





High Loading Capacity Coal Mine Dump Trucks 70 Tons With SGS ISO 0

High Loading Capacity Coal Mine Dump Trucks 70 Tons With SGS ISO 1

High Loading Capacity Coal Mine Dump Trucks 70 Tons With SGS ISO 2
