Place of Origin: | China |
Hàng hiệu: | SINOTRUK |
Chứng nhận: | ISO/3C/BV/IFA/SGS |
Model Number: | 3 Axles 50-80Tons |
Minimum Order Quantity: | 1 Unit |
---|---|
Giá bán: | Negotiation |
Packaging Details: | Nude or Waxing in Roro or bulk ship, or by 40GP, 40HQ,40FR and so on |
Delivery Time: | 20 working days after received your advance payment |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 4,000units per month |
Tên sản phẩm: | Xe tải rơ moóc giường thấp | Mô hình: | 3 trục 50-80 tấn |
---|---|---|---|
Bánh xe thứ năm: | # 50, # 90 | Khả năng tải: | 50-80 tấn |
Kích thước của căn hộ: | 13000 * 3000mm | Trục: | 3X16 tấn |
Vật chất: | Thép carbon hoặc thép Mn | Thiết bị hạ cánh: | CÔNG VIỆC 28T |
Điểm nổi bật: | Semi Trailer Dump Truck,semi flatbed trailers |
Low-bed Semi Trailer Truck 3 Axles 80Tons 17m for Loading construction machines
Description:
Low-bed Semi Trailer Truck 3 Axles 80Tons 17m for Loading construction machine
Our company's Low bed semi trailer which exported to so many countries, such as Asia countries, Africa countries, South America countries and so on.
Which is popular used in Mining industry, Construction business and so on.
Specification:
Low-bed Semi Trailer Truck 3 Axles 80Tons 17m for Loading construction machines |
|
Model | 3 Axles 60Tons |
Axle |
FUWA brand, 16ton, 2 Sets |
Main beam |
Beam height: 500mm Upper plate: 10mm Double Middle plate: 6 mm Down plate: 12mm |
Dimension of Flat |
13000*3000*6mm |
Material |
Carbon steel or Mn steel |
Gross vehicle weight |
75000kgs |
King pin |
#90 |
Support leg |
JOST Standard 28T |
Suspension |
Normal suspension |
Thickness leaf spring |
10/10/10 |
Tire/Rim |
1200R20, 13pcs, 8.5, 12 pcs |
Brake Chamber |
Standard 6 pcs |
Spare wheel carrier |
2 pcs |
Tool box |
1 pcs |
Electrical System |
Chinese standard 24C lighting system |
Side Maker Lamp |
LED lamp |
Painting |
Polyurethane Paint |
Overall dimension |
16000×2500×3880(mm) |
Color | White, red, green, golden and so on. |
Applications:
Low bed semi trailer for a variety of mechanical equipment, large objects, highway construction equipment, large tanks, power station equipment for various steel transportation.
Competitive Advantage:
1) Our company produces low flat semitrailer divided into flat, concave beam and tire exposed structure, beam adopts flat type or goose neck. The frame is ladder type, the beam cross-section is
I-shaped, has high anti breaking strength and bearing capacity.
2) The main plane of the frame is low, which ensures the smooth transportation, and is suitable for carrying all kinds of engineering machinery, large equipment and steel.
3)Using three axis balance, double axis balance or rigid suspension, the mass balance block is arranged
between the front and rear leaf springs.
4) the key parts adopt the world's top technology products
5)based on strong technical support and top level technology make the trucks with high quality and more
reliable
